Sanitary stainless steel butterfly valves , 4" Manual mixing proof butterfly valve

Nama Merek:	DONJOY
Nomor Model:	NO.VDF300S1
Jumlah Pesanan Minimum:	Negotiation
harga:	Bisa dinegosiasikan
Rincian kemasan:	carton box or wooden box
Ketentuan Pembayaran:	T/T, LC, Credit Card

Informasi Rinci

Deskripsi produk

Informasi Rinci

Place of Origin:

China

Sertifikasi:

CE,3A,FDA

Product Name:

Sanitary butterfly Valve

Materials:

304/316L

Size:

DN50-DN100,2"-4"

Operation:

Manual pull handle

Max Pressure:

10Bar

Gasket:

EPDM, SILICONE,VITION

Supply Ability:

1000pcs per month

Menyoroti:

stainless butterfly valves

pneumatic butterfly valve

Deskripsi produk

4" Manual mixing proof stainless butterfly valve, industrial ss butterfly valve

Specifications

Product Name:	4" Manual mixing proof sanitary butterfly valves Stainless steel 304 /316L
Valve Body Material:	SS304/316L
Seal Material:	EPDM (standard) FPM/SILICON/NBR, FDA177.2600
Max Working Pressure:	10Bar
Max.Working Temperature:	120 degree C
Available size:	DN50-DN100,2"-4"
Available connection:	Clamp/welding/thread/special connection
Available standard:	3A/DIN/SMS/RJT/ISO/IDF
Operated:	Manual,Pneumatic, Electric
Handle application:	Two-position handle / three-position handle / four-position pull handle / multi-position plastic handle / multi-position stainless steel handle
Control:	Smart valve positioner / C-TOP control / position sensor
Certificate:	3A/54-02 (1580), PED/97/23/EC, FDA.177.2600, ISO
Application scope:	Dairy,food, beverage, pharm
Grade of handle:	3 - grade

Type:Double seat butterfly valve Type A, Double seat butterfly valve Type B
Operation: Pneumatic, manual interchangeable, C-Top Basic, C-Top+AS-1 Communication
Design and Features

Compact and robust design
Interchangeable half -bodies(any connection Type)
Connection: Weld DIN11850,Clamp DIN32676,Thread din11581,Weld ASME BPE, Clamp asme BPE

Application
Double seat butterfly valves can be used in food-processing pharmacy and chemical industries. Leakage butterfly valve offers an easy and safe separation of products and prevents accidental mixing in case of gasket failure. The most usual applications are the ones that require safe separation of the products and CIP solution in a single point(not in manifolds), or at the end of a manifold(e.g CIP return) or entry of a CIP solution into a tank(through a spray ball)

Packaging Details
Bubble pack for each valve.
Outside packing is carton or plywood cases.
Or as per the request of customers.

Delivery details
Usually within 20 days after receiving T/T down payment.

Various kinds of manual butterfly valve
Sanitary stainless steel butterfly valves , 4" Manual mixing proof butterfly valve 0
