22PSI C Top DC 24V Pneumatic Valve Controller Open Close

Nama Merek:	DONJOY
Nomor Model:	C-TOP-1421/1721
Jumlah Pesanan Minimum:	Negotiation
harga:	US $120 - 500 / Piece
Rincian kemasan:	carton box or wooden box
Ketentuan Pembayaran:	T/T, LC, Credit Card

Informasi Rinci

Deskripsi produk

Informasi Rinci

Place of Origin:

CHINA

Sertifikasi:

CE,3A,FDA

Product Name:

controller

Power:

DC 24V

Pneumatic pressure:

1.5 bar - 7 bar (22PSI to 102PSI)

Level of protection:

IP67

Operation mode:

Pneumatic operation

Working pressure:

10bar

Supply Ability:

1000pcs per month

Menyoroti:

DC 24V Pneumatic Valve Controller

22PSI Pneumatic Valve Controller

Deskripsi produk

Sanitary food stainless steel equipment controllers C-TOP pneumatic control valve open and close

SPECIFICATION

Product Name	Controller
Medium	Lubricated compressed air, inert gases
Max. Working temperature	70℃
Working pressure	1.5 bar - 7 bar (22PSI to 102PSI)
Connector	G1/8"
Level of protection	IP67
Air flow	200NL
Stroke	Min. 3mm; Max. 70mm
Max. C - TOP units	31 C - TOP units
Connecting cable	2m
AS-I BUS	max. length: 1m
Function	For controlling valve position
Feature	Inductive position sensor

Model choosing table

Controller C-TOP 1421/1721 /222a(Recommend version)
	Input control	Recommend actuator	Output signal
	1 solenoid valve	single acting pneumatic actuator	PNP 2 postiion 4-20mA
	2 solenoid valves	Double acting pneumatic actuator	PNP 2 position 4-20mA
	3 solenoid valves	for mixing proof valve	PNP 3 position 4-20mA
	3 Solenoid valves	for mixing-proof valve	PNP 4 position (including 1pc external sensor) 4-20mA

Controller C-TOP 1421/1721/2221 (Bus protocol version AS-I BUS-V3.0)
	Input control	Recommend actuator	Output signal
	1 solenoid valve	single acting pneumatic actuator	PNP 2 postiion 4-20mA
	2 solenoid valves	Double acting pneumatic actuator	PNP 2 position 4-20mA
	3 solenoid valves	for mixing proof valve	PNP 3 position 4-20mA

Applications

C - TOP is a pneumatic controller that is designed to ensure an optimum control valve.

It is compatible with most PLC automatic system. In the industry of food, beverage, pharmacy,

it could be installed to all kinds of pneumatic valves such as mixture proof valve, butterfly valve, ball valve, diaphragm valve, reversing valve and globe valve etc.

Design and features

Connecting sensors with solenoid valve ( actuator ) easily, fastly and economically by AS - I BUS mastering.

Since cables are largely decreased, installation and start up become more convenient.

Besides, start time is shortened, and some hidden troubles in the installation can be avoided.Parts are the same as standard C - TOP. The only changed part is the built - in card,. AS - I insulation replacement connector and the cable connector itself.

C - TOP Valve control unit - - 2014

Displacement regulating version

Model

Sensor

Solenoid valve

Power

Connection

Remarks

1421-05-S1-V1

DC. 24V

Cable connection

Single acting

1421-05-S1-V2

DC. 24V

Cable connection

Double acting

1421-05-S1-V3

DC. 24V

Cable connection

Three effects

(mixture proof valve)

1421-05-S1-V1-AS

DC. 24V

AS-I BUS

Single acting

1421-05-S1-V2-AS

DC. 24V

AS-I BUS

Double acting

1421-05-S1-V3-AS

DC. 24V

AS-I BUS

Three effects

(mixture proof valve)

Mechanical regulating version

Model

Sensor

Solenoid valve

Power

Connection

Remarks

1421-05-S1-V1-M

DC. 24V

Cable connection

Single acting

1421-05-S1-V1-M

DC. 24V

Cable connection

Single acting

1421-05-S1-V2-M

DC. 24V

Cable connection

Double acting

1421-05-S1-V3-M

DC. 24V

Cable connection

Three effects (mixture proof valve)

1421-05-S1-V1-AS-M

DC. 24V

AS-I BUS

Single acting

1421-05-S1-V1-AS-M

DC. 24V

AS-I BUS

Single acting

1421-05-S1-V2-AS-M

DC. 24V

AS-I BUS

Double acting

1421-05-S1-V3-AS-M

DC. 24V

AS-I BUS

Three effects (mixture proof valve)

Installation

22PSI C Top DC 24V Pneumatic Valve Controller Open Close 2

Product display

22PSI C Top DC 24V Pneumatic Valve Controller Open Close 3
